132
Thousands place: Auxiliary digital frequency stop control
0: The auxiliary frequency will be maintained upon stop
The auxiliary frequency is maintained upon stop.
1: The set frequency is reset upon stop
The auxiliary frequency is reset upon stop.
0: No auxiliary reference
The set frequency is composed of the main set frequency only and the auxiliary set frequency is 0 by
default
1: Digital reference 1, adjusting with the
∧ & ∨
keys on the operation panel
The initial value of the auxiliary frequency is P02.08, which can be adjusted with the
∧ & ∨
keys on
the operation panel.
2: Digital reference 2, adjusting with terminal UP/DOWN
The initial value of the auxiliary frequency is P02.08, which can be adjusted with the terminal UP/DOWN.
For the setting of terminal UP/DOWN, please refer to the function codes of Group P09.
3: Digital reference 3, serial port communication reference
The auxiliary frequency is set based on the serial port reference and its initial value is the value of P02.08.
The value of the auxiliary set frequency is changed through the serial port frequency setting command.
4: AI analog reference
The auxiliary frequency is set based on the AI terminal (AI1, AI2 and AI3) reference.
5: Terminal pulse (PULSE) reference
The auxiliary frequency is determined by the terminal pulse frequency and can be input by X7 or X8,
please refer to the definition in the function codes of Group P09 for details.
6: Process closed loop output
The process closed loop output is used as the auxiliary reference.
7: Expansion bus card reference
Set the reference via the expansion bus card.
Note
1. When the auxiliary frequency adopts the reference mode 4 and 5, the positive and negative polarity of the
output auxiliary frequency is determined by the selection of the function code of Group P10, which
determines whether the reference adopts the analog or pulse value, or let it determined by the function code
of Group P02.03.
2. The main and auxiliary frequency reference channels are mutually exclusive (except for the AI channel).
3. When the main frequency source selection (P02.04) is set as 5, 6 or 7, the auxiliary frequency
superimposition is not applicable. When any of the three is selected, the auxiliary frequency source selection
(P02.07) will be reset and can not be set as non-zero data.
Digital setting of auxiliary reference 0.00~3000.00 Hz(0.00)P02.08
Auxiliary reference frequency source selection 0~7 (0)P02.07
