Megmeet MV600 Series User Manual

67
Chapter 5 Parameter List
Explanation to the terms in the function code parameter table
Table field Explanation
Function code
number
Representing the number of the function code, e.g. P00.00
Function code
name
Name of the function code, explaining it
Leave-factory
value
The value of the function code after restoring the leave-factory settings
Set range The minimum and maximum values of the function code allowed to set
Unit
V: Voltage; A: Current; ℃: temperature; Ω: resistance; mH: inductance; rpm: rotate speed; ％:
percentage; bps: baud rate; Hz, kHz: frequency; ms. s, min, h. kh: time; kW: power; ⁄: No unit
Property
○: Means the function code can be changed during running; ×: Means the function code can be
changed in the stop state; ﹡: Means the function code can be read only, can not be changed
Function code
option
List of function code parameter settings
User setting Used to set parameters by users
5.1 Basic menu function code parameter table
Function
code
Name LCD display Setting range
Minimum
unit
Default
value
Menu
mode
Change
Q B
Group P00: System management
P00.00
Menu mode
selection
Menu mode
selection
0: Quick menu mode.
Only the parameters related to the
quick running of the drive will be
displayed
1: Full menu mode
All the function parameters are
displayed
2: Changing the memory menu
mode
Only the parameters that are
different from the leave-factory
values are displayed
1 0 √ √ ○
P00.01
User
password
User
password
0: No password
Other: Password protection
1 0
×
√ ○
P00.02
LCD display
language
Language
selection
0: Chinese
1: English
1 0
× √ ○
