8
Table 1-1 Name and model of drive
Enclosure
model
Product model
Rated
capacity
(kVA)
(HD)
Rated input current
(A)
Rated output current
(A)
Rated output power
(kW)
HD ND HD ND HD ND
R2
MV600G-4T0.75 1.5 3.5 5.1 2.3 3.7 0.75 1.5
MV600G-4T1.5 3.0 5.1 5.8 3.7 5.5 1.5 2.2
MV600G-4T2.2 4.0 5.8 10.5 5.5 8.8 2.2 3.7
MV600G-4T3.7 5.9 10.5 14.5 8.8 13.0 3.7 5.5
R3
MV600G-4T5.5 8.5 14.5 20.5 13.0 17.0 5.5 7.5
MV600G-4T7.5 11.0 20.5 26.0 17.0 25.0 7.5 11
R4
MV600G-4T11 17.0 26.0 35.0 25.0 32.0 11 15
MV600G-4T15 21.0 35.0 38.5 32.0 37.0 15 18.5
R5
MV600G-4T18.5 24.0 38.5 46.5 37.0 45.0 18.5 22
MV600G-4T22 30.0 46.5 62.0 45.0 60.0 22 30
MV600G-4T30 40.0 62.0 76.0 60.0 75.0 30 37
R6
MV600G-4T37 50.0 76.0 92.0 75.0 90.0 37 45
MV600G-4T45 60.0 92.0 113.0 90.0 110.0 45 55
R7
MV600G-4T55 72.0 113.0 157.0 110.0 152.0 55 75
MV600G-4T75 100.0 157.0 180.0 152.0 176.0 75 90
R8
MV600G-4T90 116.0 180.0 214.0 176.0 210.0 90 110
MV600G-4T110 138.0 214.0 256.0 210.0 253.0 110 132
R9
MV600G-4T132 167.0 256.0 307.0 253.0 304.0 132 160
MV600G-4T160 200.0 307.0 385.0 304.0 380.0 160 200
R9P MV600G-4T200 250.0 385.0 430.0 380.0 426.0 200 220
R10
MV600G-4T220 280.0 430.0 525.0 426.0 495.0 220 280
MV600G-4T280 355.0 525.0 590.0 495.0 585.0 280 315
MV600G-4T315 445.0 590.0 665.0 585.0 650.0 315 355
R11
MV600G-4T355 500.0 665.0 785.0 650.0 725.0 355 400
MV600G-4T400 565.0 785.0
－
725.0
－
400
－
1.4 Technical specifications of product
Table1-2 Technical specifications of drive
Input power
Rated voltage (V)
Three-phase: 380V~480V; continuous fluctuation of voltage:
±10%, transient fluctuation of voltage: -15%~+10% (i.e. the
range is 323V~528V); Voltage unbalance rate: ＜3%, the
distortion rate complies with IEC61800-2
Rated input current (A) Please refer to Table 1-1.
Rated frequency (Hz) 50Hz/60Hz, fluctuation range: ±5%
Output power
Standard applicative motor (kW)
Please refer to Table 1-1.
Rated capacity (kVA)
