9
Rated current (A)
Output voltage (V)
Output with three-phase under rated input conditions, 0 ~ rated
input voltage, the error is less than ±3%
Output frequency (Hz) V/F: 0.00~3000.0Hz (unit: 0.01Hz); vector control: 0~650.00Hz
Overload capacity
HD: 1 min for 150% rated current, 0.5 s for 200% rated current
ND: 1 min for 120% rated current, 2 s for 150% rated current
Operation control
features
Control mode
Vector control without PG, Vector control with PG, V/F
control without PG, V/F control with PG
Maximum output frequency 3000Hz for V/F control, 650Hz for other control
Speed adjusting range
1: 200 (vector control without PG)
1: 1000 (vector control with PG)
Speed control precision
±0.2% (vector control without PG)
±0.02% (vector control with PG)
Speed fluctuation
±0.3% (vector control without PG)
±0.1% (vector control with PG)
Positioning precision < ±1 pulse
Torque response
<5ms (vector control with PG)
<10ms (vector control without PG)
Torque control
The torque control precision is 7.5% when vector control without
PG, and 5% when vector control with PG
Startup torque
150% @ 0Hz (vector control without PG); 200% @ 0Hz (vector
control with PG)
Product functions
Key functions
Fast tracking, over torque / under torque detection, torque limit,
multi-stage speed operation, multiple acceleration/deceleration
time switching, auto-tuning, S curve acceleration/deceleration,
slip compensation, fan speed control, skip frequency operation,
energy saving operation, PID adjustment (sleep function),
non-stop upon instantaneous power interruption, switching of
multi-command, MODBUS communication, drooping control,
torque control, torque and speed control mode switching,
automatic restart, DC braking, dynamic braking; simple PLC,
dwell function, two sets of motor parameters switching; fieldbus
communication
Basic frequency
0.01Hz~3000.0Hz
Startup frequency
0.00Hz~60.00Hz
Frequency setting mode
Digital panel setting, terminal UP/DN setting, host device
communication setting, analog setting (AI1/AI2/AI3), terminal
pulse setting, fieldbus communication setting
Acceleration/deceleration time 0.1~3600.0 (unit can be selected among 0.1s, s and min)
Dynamic braking capacity
Models of 75kW and below have built-in braking unit as
standard, and the braking rate is 0.0~100.0%
DC braking capacity
Initial frequency: 0.00Hz~60.00Hz
Braking time: 0.1s~30.0s
Braking current: 0%~100% for HD, 0%~80% for ND; according
