266
Read the output current of No.5 drive and the response output current is 30.0A (32 bits mode):
Data
frame
Address Command code
Register
address
Number of registers or
number of bytes read
Register
content
Check code
Request 0x05 0x03 0xE506 0x0002 None 0x1282
Response 0x05 0x03 None 0x04
0x000001
2C
0xBFBE
Read the deceleration time 1 (i.e. P02.14) of No.5 drive and the response deceleration time is 6.0s (16 bits
mode):
Data
frame
Address Command code
Register
address
Number of registers or
number of bytes read
Register
content
Check code
Request 0x05 0x03 0x020E 0x0001 None 0xE5F5
Response 0x05 0x03 None 0x02 0x003C 0x4995
Read the deceleration time 1 (i.e. P02.14) of No.5 drive and the response deceleration time is 6.0s (32 bits
mode):
Data
frame
Address
Command
code
Register
address
Number of registers or
number of bytes read
Register
content
Check code
Request 0x05 0x03 0x820E 0x0002 None 0x8C34
Response 0x05 0x03 None 0x04 0x0000003C 0xBFE2
11. Scaling of drive parameters
1. Scaling of the frequency: 1:100
To make the drive run at 50 Hz, the main setting shall be 0x1388 (5000).
2. Scaling of time: 1:10
To make the acceleration time of the drive to be 30 s, the function code shall be set as 0x012C (300).
3. Scaling of current: 1:10
If the feedback current of the drive is 0x012C (300), the present current shall be 30 A.
4. The output power is its absolute value.
5. For other parameters, please refer to the function parameter descriptions.
