134
7: Switching between main and auxiliary reference frequency source
When any function code of terminals P09.00~P09.07 is selected as 20, the reference frequency source
can be switched between the main reference frequency source and auxiliary reference frequency source
via the terminal change.
8: Switching between main reference frequency source and (main + auxiliary) reference frequency
source
When any function code of terminals P09.00~P09.07 is selected as 20, the reference frequency source
can be switched between the main reference frequency source and (main + auxiliary) reference
frequency source via the terminal change.
9: Switching between auxiliary reference frequency source and (main + auxiliary) reference frequency
source
When any function code of terminals P09.00~P09.07 is selected as 20, the reference frequency source
can be switched between the auxiliary reference frequency source and (main + auxiliary) reference
frequency source via the terminal change.
Note
When 0 selected for P02.07 and the auxiliary setting is disabled, the main/auxiliary calculation rule P02.10 will
be disabled, and the set frequency will be determined by the main set frequency.
This function determines the adjustment mode of the set frequency (the combined frequency after the
main set frequency is added with the auxiliary set frequency). For the following frequency code, please
refer to Fig.6-5.
0: Disabled
Do not adjust the set frequency that is combined by the main and auxiliary set frequency, that is,
43
ff =
1: Adjust according to the maximum output frequency P02.15
Set frequency
%)10012.02(15.02
34
−×+= PPff
2: Adjust according to the current frequency
Set frequency
12.02%)10012.02(
3334
PfPfff ×=−×+=
The acceleration time means the time needed for the drive to accelerate from 0Hz to the maximum output
frequency (P02.15). The deceleration time means the time needed for the drive to decelerate from the
maximum output frequency (P02.15) to 0Hz.
Note
1.The time unit (min, s, 0.1s) of the acceleration/deceleration time 1~4 can be selected through P11.01 and
the default leave-factory unit is second.
2. For the drive of 5.5~22kW, the leave-factory value for its acceleration/deceleration time is 6.0s, for the drive
of 30~45kW, it is 20.0s, and for other modes of drives, it is 30.0s.
Deceleration time1 0.0~3600.0s (6.0s)P02.14
Acceleration time 1 0.0~3600.0s (6.0s)P02.13
Proportion adjustment coefficient of set frequency 0.0~200.0% (100.0%)P02.12
Proportion adjustment selection of set frequency 0~2 (0)P02.11
