Megmeet MV600 Series User Manual

194
0: 0.1s
1: s
2: min
This function is used for defining the time unit for all the acceleration/deceleration operations, except for
the jog operation.
The acceleration time means the time needed for the drive to accelerate from 0Hz to the maximum output
frequency (P02.15), as t
1
shown in Fig. 6-56. The deceleration time means the time needed for the drive
to decelerate from the maximum output frequency (P02.15) to 0Hz, as t
2
shown in Fig. 6-56.
MV600 series drive has four acceleration/deceleration time settings in total. The
acceleration/deceleration time (1~4) of the drive in the operation can be selected by different
combinations of control terminals. Please refer to the definition on functions of the
acceleration/deceleration time terminal in P09.00~P09.07. They can be also defined as the
acceleration/deceleration time for the running frequency switch between various stages when the drive is
running in the simple PLC mode. Please refer to the description in P13 parameter group.
 Note
The time unit (minute, second) of the acceleration/deceleration time 1~4 can be selected via P11.01 and the
default leave-factory unit is second.
P11.08~P11.13 set S curve, and the setting of S curve can be divided into acceleration, fast acceleration
(jerk) and deceleration and fast deceleration (decreasing the deceleration), as shown in Fig.6-58.
Fast deceleration at end se
g
ment of S curve 0.20~600.00Hz/s2
(
12.50
)
P11.13
Fast deceleration at start se
g
ment of S curve 0.20~600.00Hz/s2
(
20.00
)
P11.12
S curve deceleration 10.00~600.00Hz/s
(
25.00
)
P11.11
Fast acceleration at end se
g
ment of S curve 0.20~600.00Hz/s2
(
20.00
)
P11.10
Fast acceleration at start se
g
ment of S curve 0.20~600.00Hz/s2
(
12.50
)
P11.09
S curve acceleration 10.00~600.00Hz/s
(
25.00
)
P11.08
Deceleration time 4 0.0~3600.0
(
6.0
)
P11.07
Acceleration time 4 0.0~3600.0
(
6.0
)
P11.06
Deceleration time 3 0.0~3600.0
(
6.0
)
P11.05
Acceleration time 3 0.0~3600.0
(
6.0
)
P11.04
Deceleration time 2 0.0~3600.0
(
6.0
)
P11.03
Acceleration time 2 0.0~3600.0
(
6.0
)
P11.02
