Megmeet MV600 Series User Manual

214
Wiring mode:
0 : Cable (RS485)
1 : MODEM
Tens Unit
Hundreds
Baud rate :
1: 9600bps
0: 4800bps
3: 38400bps
2: 19200bps
5: 125000bps
4: 115200bps
Data format:
0:1-8-2-N,RTU
1: 1-8-1-E, RTU
2:1-8-1-O, RTU
3:1-7-2-N, ASCII
4: 1-7-1-E, ASCII
5:1-7-1-O, ASCII
(Need RS232/RS485 conversion)
Fig. 6-75 Setting of communication configuration
This function is used for selecting parameters for serial communication port and setting according to LED
bits.
If the hundreds place of the function code is in MODEM mode, whenever the drive powers up, the
initialization operation will be performed once for MODEM via RS485 port on the control board, so that
the MODEM can automatically response after receiving 3 times of ringing signal of telephone line to
realize the remote control line made up from dial-up line.
Note: MV600 control board provides RS485 port only. If the communication port of the external
equipment is RS232, the RS232/RS485 conversion equipment shall be added separately.
This function code is used for marking the address of drive.
Note: 0 is the broadcast address. If it is set as the broadcast address, it can only receive and execute the
broadcast command from the host device, and will not respond to the host device.
When the serial port communication signal disappears for a period of time exceeding the set value of this
function code, the drive is considered as communication fault.
When the set value is 0, the drive will not detect the serial port communication signal.
The serial port of the drive receives and executes commands from the host device, until going back to the
delay time which the response frame gave to the host device. For the RTU mode, the actual response
delay shall be no less than the transmission time of 3.5 characters.
Reserved.
Reserved.
Reserved function 2 for use
r
0~65535
(
0
)
P15.06
Reserved function 1 for use
r
0~65535
(
0
)
P15.05
Res
p
onse dela
y
of the drive 0~1000ms
(
5ms
)
P15.04
Communication timeout detection time 0.0~1000.0s
(
0.0s
)
P15.03
Local address 0~247
(
5
)
P15.02
