219
Fig. 6-80 Fault protection and alarm property setting 2
Fig. 6-81 Fault protection and alarm property setting 3
In certain abnormal situations, the drive can shield faults and stop actions and keep operating by setting
P97.00, P97.01 and P97.02.
The operation panel at that moment will display an alarm AL.XXX (XXX represents the alarm code. For
details, please refer to Chapter 7 Troubleshooting).
P97.00 defines the protection action selections for abnormal communication, abnormal contactor,
abnormal EEPROM and 24V/±10V short circuit.
Fault protection and alarm property setting 3 0~2113H (0000)P97.02
