Page #88 background image
88
X1~X8 control input
4: External jog reverse running
control input
5: Three-wire operation control
6: Multi-stage reference terminal 1
7: Multi-stage reference terminal 2
8: Multi-stage reference terminal 3
9: Multi-stage reference terminal 4
10: Acceleration/deceleration time
terminal 1
11: Acceleration/deceleration time
terminal 2
12: Main reference frequency
pulse input (valid only for X7 &
X8)
13: Auxiliary reference frequency
pulse input (valid only for X7
orX8)
14: Frequency increase command
(UP)
15: Frequency decrease
command (DN)
16: External fault normally open
input
17: External fault normally closed
input
18: External interrupt normally
open contact input
19: External interrupt normally
closed contact input
20: Reference frequency source
switching command
21: Reserved
22: External reset (RESET) input
23: Coast to stop input (FRS)
24: Acceleration/deceleration
disable command
25: Stop DC braking input
command
26: Simple PLC pause command
27: Reserved
28: Clearing the PLC stop
memory
29: PID disabled
30: PID closed loop soft-start
disabled
31: PID integral retention
32: PID integral clearing
33: Switching PID adjustment
0
0
0
0
