CYLINDER HEAD
90-828631R3 MARCH 1999 Page 4A-13
Cylinder Head Cover Installation
1. Reinstall the cylinder head cover. Tighten bolts to the specified torque.
53734
a
b
a-Retainer
b-Mounting Bolts (7)
Cylinder Head Cover Bolt Torque
70 lb-in. (8 Nm)
2. Reinstall the fuel pump. Tighten bolts to the specified torque.
3. Reconnect the breather hose and vent hose. Use sta-straps to fasten all hose connec-
tions.
53726
a
b
c
a
b
c
a-Fuel Pump
b-Vent Hose
c-Breather Hose
Fuel Pump Mounting Bolt Torque
75 lb-in. (8.5 Nm)
