NON-BIGFOOT GEAR HOUSING
Page 6A-28 90-828631R3 MARCH 1999
Shift Shaft
1. Inspect shift cam for wear or galling. Replace cam if necessary.
2. If cam is worn, inspect cam follower in end of propeller shaft for wear.
52845
b
a
a-Cam Follower
b-Shift Cam
3. Inspect shift shaft boot for deterioration.
4. Inspect shift shaft carrier O-ring for cuts or abrasions. It is a good service procedure to
replace all O-rings, seals and gaskets regardless of appearance.
52828
a
b
a-Boot
b-O-ring
