NON-BIGFOOT GEAR HOUSING
Page 6A-4190-828631R3 MARCH 1999
NOTE: Applying 2-4-C w/Teflon to cam follower will aid in retention of follower in propeller
shaft during installation of propeller shaft assembly into gear case.
6. Install cam follower.
52826
95
95
2-4-C w/Teflon (92-850736A1)
a
a-Cam Follower
7. Install propeller shaft assembly into gear case.
52864
a
a-Propeller Shaft Assembly
To Next Page
