NON-BIGFOOT GEAR HOUSING
Page 6A-4390-828631R3 MARCH 1999
4. Torque bolts to specified torque.
7
7
7
Loctite “271” (92-809819)
a
a
a-Bolts
Bearing Carrier Bolt Torque
18.8 lb-ft (25.4 Nm)
Water Pump
1. Install water pump seal carrier.
2. Install exhaust deflector plate, if removed.
52832
b
a
a-Seal Carrier
b-Exhaust Deflector
To Next Page
