Mercury 50

TILLER HANDLE
90-828631R3 MARCH 1999 Page 7B-13
3. If removed, install hardware to the throttle lever as shown.
50 HP Models
45 HP Models
a
b
c
d
a
a-Screw
b-Nut
c-Cap
d-Bushing
4. Install throttle lever.
a
b
95
2-4-C w/Teflon (92-850736A1)
95
a-Bushing (Existing)
b-Screw (Existing)
Throttle Lever Screw Torque
100 lb-in. (11.3 Nm)
