TILLER HANDLE
Page 7B-14 90-828631R3 MARCH 1999
5. 50 HP Models – adjust screw to allow for some free play in the carburetor linkage at wide
open throttle. Do not allow the carburetor shutters to act as throttle stops.
NOTE: 45 HP Models – the throttle stop is fixed and does not require adjustment.
54281
6. Install switch assembly.
NON-BIGFOOT
a. S/N 0G472132 and below.
54277
a
b
c
a-Switch Assembly
b-Backing Plate
c-Screw (2)
