ENGINE MECHANICAL SERVICE MANUAL NUMBER 22
Page 3A-80 90-860074--1 FEBRUARY 2002
10. Remove flywheel holder tool.
11. Install seawater pump using a new O-ring seal.
12. Install alternator brace to timing cover, using the bolt, washer, spacer and nut removed
during disassembly. Torque nut to 45-50 Nm (34-37 lb-ft).
75106
a
b
c
d
e
f
a-Brace
b-Timing Cover
c-Screw
d-Washer
e-Spacer
f-Flange Nut
13. Tension the alternator belt, power steering belt, and vacuum pump belt, if equipped.
Torque drive belt related mounting and tensioning bolts to specifications.
14. Install seawater pump inlet hose and outlet hose. Tighten hose clamps securely.
15. Open the seacock if equipped, or remove plug from seawater inlet hose and reconnect
seawater inlet hose to inlet of seawater strainer.
To Next Page
