ENGINE MECHANICAL

SERVICE MANUAL NUMBER 22

90-860074--1 FEBRUARY 2002 Page 3A-83

Reassembly

1. Install the bevelled end of the outer rotor towards the pump gear.

2. Ensure that the rotor and gear coupling resists a rolling torque of 9 kgm (32.4 oz.).

Installation

1. Install oil pump in cylinder block. Torque screws to 27.5 Nm (20 lb-ft).

70292

a-Screws (3)

b-Oil Pump

2. Install timing gear cover.
