MAINTENANCE SERVICE MANUAL NUMBER 22
Page 1B-6 90-860074--1 FEBRUARY 2002
Capacities
NOTICE
All capacities are approximate fluid measures.
Engines
NOTICE
Unit Of Measurement: Liters (U.S. Quarts).
Model
D2.8L
D-Tronic
D4.2L
D-Tronic
Total Oil Capacity
1
10 ( 8-1/2 ) 12 ( 12-3/4 )
Oil Pan 8 ( 6-1/2 ) 10 ( 10-3/4 )
Oil Drainage
Oil Filter 1 ( 1 )
Oil Cooler 1 ( 1 )
Closed Cooling Circuit 11 ( 11-2/3 ) 13 ( 13-3/4 )
1
Always use dipstick to determine exact quantity of oil required
Drives
NOTICE
Unit Of Measurement: Liters (U.S. Quarts).
Item Specification
Bravo One 2.6 (2.75)
Drive Unit Oil Capacity (With Gear Lube
Bravo Two 3 (3.2)
Monitor)
Bravo
Three
2.9 (3)
Transmissions
IMPORTANT: It may be necessary to adjust oil levels depending on installation angle
and cooling systems (heat exchanger and fluid lines).
NOTICE
Unit Of Measurement: Liters (U.S. Quarts).
Make And Model Specification
1
Fluid Type
Hurth 630A
3 (3-1/4)
Dexron III Automatic
630V
4 (4-1/2)
Dexron III Automatic
Transmission Fluid
1
Always use dipstick to determine exact quantity of oil required
