PUMP AND RELATED COMPONENTS SERVICE MANUAL NUMBER 22
Page 9A-4 90-860074--1 FEBRUARY 2002
Related Components
ALL ENGINES
71034
9
6
7
1
8
2
5
3
4
78418
1-Fluid Reservoir Tank
2-Hose Clamp (2)
3-Fluid Reservoir Support
4-Bracket
5-Supply Hose
6-Pressure Hose
7-Return Hose (From Transom)
8-Return Hose (From Cooler)
9-Power Steering Fluid Cooler
