ZF / HURTH TRANSMISSIONS
SERVICE MANUAL NUMBER 22
90-860074--1 FEBRUARY 2002 Page 8A-5
Torque
Description Nm lb-in. lb-ft
Transmission Housing Halves Bolts and Nuts 49 36
Control Block-To-Housing 25 18
Output Flange 18 14
Mounts
Transmission To Flywheel Housing
61 45
Tools
Description Part Number
Thermometer [(3/8-NPT, Thread -18 to -132°C (0-270°F)]
Pressure Gauge (0-500 psi), (1/8-NPT)
Obtain Locally
Lubricants / Sealants / Adhesives
Description Part Number
Quicksilver Engine Coupler Spline Grease 92-816391A4
Quicksilver Liquid Neoprene 92-25711--3
Loctite Type A
Loctite 515
Obtain Locally
