ENGINE MECHANICAL
SERVICE MANUAL NUMBER 22
90-860074--1 FEBRUARY 2002 Page 3A-81
Oil Pump
Removal
1. Remove the timing gear cover.
2. Remove the screws securing oil pump.
70292
a
b
a-Screws (3)
b-Oil Pump
3. Remove the oil pump from bore in block.
70287
a
a-Oil Pump
Cleaning
1. Dismantle and wash all parts in cleaning solvent.
2. Put on safety glasses.
3. Dry parts with compressed air.
