GLOW PLUG SYSTEM SERVICE MANUAL NUMBER 22
Page 4C-6 90-860074--1 FEBRUARY 2002
Removal
1. Disconnect battery cables from battery.
2. Remove hex nut and washer from glow plug terminal.
3. Remove voltage supply wire.
4. Remove glow plug connecting wire from glow plug terminal.
77940
a
c
b
a-Voltage Supply Wire
b-Glow Plug Terminal
c-Glow Plug Connecting Wire
IMPORTANT: Avoid contaminating cylinders. Clean any corrosion or debris away
from around glow plug before removal.
5. Clean any dirt away from around glow plug and opening in cylinder head.
6. Remove glow plug.
To Next Page
