CHARGING SYSTEM SERVICE MANUAL NUMBER 22
Page 4B-4 90-860074--1 FEBRUARY 2002
Specifications
Description Specification
Excitation Circuit 1.3-2.5 Volts
Current Output 65 Ampere
Voltage Output 13.9-14.7 Volts
Condenser Capacity .5 MFD
V-Belt Tension 5 mm (3/16 In.)
1
1
: Depress belt with thumb at midway point between circulating pump pulley and alternator.
Torque Specifications
Description Nm lb-in. lb-ft
Pulley Nut 58 33
Alternator Brace to Alternator 28 20
Alternator Brace to Engine Block 41 30
Alternator to Mounting Bracket 48 35
Alternator Mounting Bracket to Engine Block 41 30
