SEAWATER COOLING SYSTEM
SERVICE MANUAL NUMBER 22
90-860074--1 FEBRUARY 2002 Page 6A-27
Seawater Strainer
Exploded View
b
h
a
f
d
c
g
78157
1
2
3
4
5
6
7
8
8
Typical
1-Drain Plug and Gasket
2-Filter Housing
3-Filter Element
4-O-ring Seal
5-Clear Lens
6-Lens Cover
7-Nozzle (2)
8-Cover Screw with Washer
