ENGINE MECHANICAL SERVICE MANUAL NUMBER 22
Page 3A-132 90-860074--1 FEBRUARY 2002
REAR MAIN BEARING
IMPORTANT: Be certain to press bearing so as to prevent damage to notch
arrangement in carrier where bearing tab aligns.
1. Using a suitable mandrel press bearing out of carrier.
2. When pressing new bearing into carrier, bearing tab and notch in carrier MUST BE
aligned as shown.
70382
a
b
a-Bearing Tab
b-Notch In Carrier
REAR MAIN BEARING CARRIER
1. Refer to Rear Oil Seal - Installation and install new seal in carrier.
70406
a
b
a-Rear Main Oil Seal
b-Rear Main Bearing Carrier
