ENGINE MECHANICAL SERVICE MANUAL NUMBER 22
Page 3A-134 90-860074--1 FEBRUARY 2002
5. Lubricate crankshaft journal and bearing with clean engine oil. Install rear main bearing
carrier into cylinder block, align marks previously made. Always be certain lubrication
holes on block and carrier align, especially when or if marks are not present.
70409
a
b
a-Rear Main Bearing Carrier
b-Marks Aligned
6. Install new O-ring into groove of thrust plate (crankshaft side).
70304
a
b
a-Thrust Plate
b-O-ring
7. Install thrust plate with O-ring towards crankshaft. Tighten retaining screw securely.
