INSTRUMENTATION SERVICE MANUAL NUMBER 22
Page 4D-28 90-860074--1 FEBRUARY 2002
LATE MODEL WIRING HARNESS CONNECTIONS
a
c
d
77223
b
e
f
g
Typical
a-Primary (MAIN PANEL) Station Instrumentation and Harness
b-Primary Station Extension Harness
c-Second (2nd PANEL) Station Instrumentation and Harness
d-Second Station Extension Harness
e-Y-Harness
f-Extension (“ENGINE”) Harness
g-To Engine
