INTERCOOLER
SERVICE MANUAL NUMBER 22
90-860074--1 FEBRUARY 2002 Page 7A-5
D2.8L Intercooler (continued)
1-Radiator Insert (Heat Exchanger Core)
2-Intercooler Housing
3-Side Intake Duct
4-Rear Intake Duct
5-Front Cover
6-Rear Cover
7-O-ring (4 On Engines Equipped With Plate, 3 On Others)
8-Plate (If Equipped)
9-Anode
10 - Anode Plug With Sealing Washer
11 - Drain Plug With Sealing Washer
12 - Rear Intake Duct Screw and Washer
13 - Gasket
14 - Intake Duct Screw
15 - End Cover Screw
16 - Nut and Washer
Description Part Number
A Loctite 514 Obtain Locally
Description Nm lb-in. lb-ft
Intake Duct Screw
Rear - (All Models) 10 84
A
Side (D21.8L D-Tronic
Only)
10 84
B End Cover Screw 40 30
C Anode Plug 13 120
D Intercooler Housing Nut 32 24
To Next Page
