TURBOCHARGER SERVICE MANUAL NUMBER 22

Page 7C-4 90-860074--1 FEBRUARY 2002

Torque Specifications

Description lb-ft Nm

Turbocharger Mounting Nuts 18 24

Clamping Plate Nuts or Screws 22 30

Wastegate-to-Exhaust Manifold Mounting Nuts 18 24

Valve-to-Wastegate Screws

Tighten Securely (Equally, in a

diagonal pattern.)

Lubricants / Sealants / Adhesives

Description P/N

Loctite 514 92-75505-1

Gasket Sealer 92-72592-1
