Section 3 - On the Water
90-879172181 eng FEBRUARY 2011 Page 37
Joystick Input and Boat Response Table
Joystick Input Boat Response
Movement
(shown from light gray to dark gray)
24704
Boat at rest
25911
24705
Boat moves forward
25928
24706
Boat moves aft
25927
24707
Boat moves to starboard without rotating
25929
