Mercusys AC1200 User Manual

AC12G
AC1200 Wireless Dual Band Gigabit Router
• Bind - Click to add an entry to the IP & Mac binding list.
Click Refresh to refresh all items.
To add an IP & MAC Binding entry, follow the steps below.
1. Click Add.
2. Enter the Host name.
3. Enter the MAC Address of the device.
4. Enter the IP Address that you want to bind to the MAC address.
5. Click Save.
To edit an existing entry, follow the steps below.
1. Find the entry in the table.
2. Click
in the Edit column.
3. Enter the parameters as you desire, then click Save.
To delete existing entries, select the entries in the table, then click Delete Selected.
To delete all entries, click Delete All.
5.2 2.4GHz Wireless
There are two submenus under the Wireless menu: Host Network and Guest Network. Click
any of them, and you will be able to configure the corresponding function.
5.2.1 Host Network
Go to 2.4GHz Wireless→Host Network, you can configure the settings for the 2.4GHz wireless
host network on this page.
- 31 -

Mercusys AC1200 Specifications

General

Power Supply	9V/0.85A
Wireless Standards	IEEE 802.11ac/n/a 5 GHz, IEEE 802.11n/b/g 2.4 GHz
Frequency	2.4 GHz and 5 GHz
Signal Rate	300 Mbps at 2.4 GHz, 867 Mbps at 5 GHz
Ports	1 x 10/100 Mbps WAN port, 4 x 10/100 Mbps LAN ports
Antenna	4 x fixed antennas
Button	Reset
Wireless Security	WPA/WPA2, WPA-PSK/WPA2-PSK
Dimensions	222 x 140 x 32 mm
