Mercusys AC1200 - Introduction; Product Overview; Product Appearance

AC12G
AC1200 Wireless Dual Band Gigabit Router
Chapter 1. Introduction
1.1 Product Overview
The router integrates 4-port Switch, Firewall, NAT-Router and Wireless AP. Powered by 2x2
MIMO technology, the router delivers exceptional range and speed, which can fully meet the
need of Small Office/Home Office (SOHO) networks and the users demanding higher
networking performance.
1.2 Product Appearance
1.2.1 The Front Panel
The router’s LEDs are located on the front panel (View from left to right).
Name
Status
Indication
SYS
Off
Power is off or the router is not working properly.
On
The router is working properly.
WI-FI
Off
The wireless function is disabled.
On
The wireless function is working properly.
WAN
Off
The WAN port is not connected.
On
The WAN port is connected.
Flashing
The WAN port is transmitting/receiving data.
LAN
Off
None of LAN ports are connected.
On
At least one LAN port is connected.
- 2 -
