Mercusys AC1200 User Manual

AC12G
AC1200 Wireless Dual Band Gigabit Router
2. Enter the port number to be used to access the router between 1024 and 65535. The
default value is 8888.
3. Click Save.
To allow specified devices to access and manage the router remotely, follow the steps
below:
1. Select Allow specified remote devices.
2. Enter the IP Address you will use when accessing your router from the Internet.
3. Enter the port number to be used to access the router between 1024 and 65535. The
default value is 8888.
4. Click Save.
5.6.2 Time Settings
Go to System Tools→Time Settings, and then you can configure the time on the following
page.
NOTE:
1.
To access the router, you should type your router's WAN IP address into your browser's
address field, followed by a colon and the custom port number (e.g.
http://
202.96.12.8:8080). After entering the correct password, you will be able to access
the router's web management page.
2. Be sure to set a very secure password for the router.
- 48 -

Mercusys AC1200 Specifications

General

Power Supply	9V/0.85A
Wireless Standards	IEEE 802.11ac/n/a 5 GHz, IEEE 802.11n/b/g 2.4 GHz
Frequency	2.4 GHz and 5 GHz
Signal Rate	300 Mbps at 2.4 GHz, 867 Mbps at 5 GHz
Ports	1 x 10/100 Mbps WAN port, 4 x 10/100 Mbps LAN ports
Antenna	4 x fixed antennas
Button	Reset
Wireless Security	WPA/WPA2, WPA-PSK/WPA2-PSK
Dimensions	222 x 140 x 32 mm
