Mercusys AC1200 User Manual

AC12G
AC1200 Wireless Dual Band Gigabit Router
• Downstream Bandwidth - The download speed through the WAN port for Guest Network.
• Set Guest Access Time - During this time the wireless stations could access the AP.
Click Save to make the settings effective.
5.4 Network Control
There are two submenus under the Network Control menu: Parental Controls and Access
Control. Click any of them, and you will be able to configure the corresponding function.
5.4.1 Parental Controls
Go to Network Control→Parental Controls, and then you can configure the parental controls
in the screen. The Parental Controls function can be used to control the internet activities of
the child, limit the child to access certain websites and restrict the time of surfing.
• Parental Controls - Click to enable or disable this function.
• Parental Devices - Displays the MAC address of the controlling PC.
• Edit - Here you can edit an existing entry.
• Add - Click to add a new device.
• Delete All - Click to delete all devices in the table.
- 36 -

Mercusys AC1200 Specifications

General

Power Supply	9V/0.85A
Wireless Standards	IEEE 802.11ac/n/a 5 GHz, IEEE 802.11n/b/g 2.4 GHz
Frequency	2.4 GHz and 5 GHz
Signal Rate	300 Mbps at 2.4 GHz, 867 Mbps at 5 GHz
Ports	1 x 10/100 Mbps WAN port, 4 x 10/100 Mbps LAN ports
Antenna	4 x fixed antennas
Button	Reset
Wireless Security	WPA/WPA2, WPA-PSK/WPA2-PSK
Dimensions	222 x 140 x 32 mm
