AC1200 Wireless Dual Band Gigabit Router
• Delete All - Click to delete all the entries in the table.
• Delete Selected - Click to delete selected entries in the table.
To set up a virtual server entry:
1. Click Add.
2. Select a service from drop-down list to automatically populate the appropriate port
number in the External Port field. If the service that you want to use is not listed, enter the
number of the service port or service port range in the External Port field.
3. Leave the Internal Port blank if it is the same as the External Port, or enter a specific port
number if the External Port is a single port.
4. Enter the IP address of the computer running the service application in the IP Address
field.
5. Select the protocol used for this application in the Protocol drop-down list, either TCP,
UDP, or All (All protocols supported by the router).
6. Click Save.
To modify an existing entry:
1. Find the desired entry in the table.
2. Click in the Edit column.
3. Click Save to make the settings effective.
Please make sure the external port is different from the port use
d for local and remote
management, or the virtual server may not be working properly.
- 42 -
