MW300D

300Mbps Wireless N ADSL2+ Modem Router

- 19 -

both sent in RIP2 format. The difference is that RIP2-M using Multicast, while RIP2-B

using Broadcast format.

• Direction: Select this option to specify the RIP direction. None is for disabling the RIP

function. Both means the ADSL modem router will periodically send and accept

routing information, and then incorporate them into routing table. IN only means the

ADSL modem router will only accept but will not send RIP packet. OUT only means the

ADSL modem router will only send but will not accept RIP packet.

• Multicast: Select IGMP version, or disable the function. IGMP (Internet Group

Multicast Protocol) is a session-layer protocol used to establish membership in a

multicast group. The ADSL ATU-R supports both IGMP version 1 (IGMP v1), IGMP v2

and IGMP v3. Select Disabled to disable it.

• Mac Clone: ISP just permits only one computer with the authenticated MAC address

to access the Internet. In this case, you can enable MAC Clone function to allow more

computers to access the Internet via the same account.

2) Static IP Address

Select this option if your ISP provides static IP information to you. You should set Static IP

Address, IP Subnet Mask, and Gateway address in the screen below.

Note:

Each IP address entered in the fields must be in the appropriate IP form, which is four IP octets

separated by a dot (x.x.x.x), such as 192.168.1.100. The modem router will not accept the IP

address if it is not in this format.
