When the DF1 input rolls over to zero, the MM-IM’s integrated value will increase to
32,768, and continue increasing following further roll-overs.
 Note: This means that the integrated value presented to the DG will often be different
from the current value being read from the I/O. Similarly, the value that Straton has
for an integrated input is likely to be the value read in from the I/O, and may not be
identical to the value that the DG has for the same point. This is because the value
presented to the DG will take in to account any roll-overs that may occur, to make full
use of the 32-bit range of the point.
