Metrohm 761 Compact IC - Page 17

1.2 Parts and controls
761 Compact IC
7
1 Door to interior 36 Filter unit PEEK (6.2821.120)
4
Aspirating tubing
for aspirating the sample;
6.1803.020 PTFE tubing,
length L = 52 cm
37 Connection capillary
6.1831.010 PEEK capillary,
length L = 13 cm
26 Inlet capillary for injector
6.1831.010 PEEK capillary,
length L = 24 cm
38 Connection capillary
6.1831.010 PEEK capillary,
length L = 15 cm
27 Mounting rail
for 6.2027.0X0 column holder
39 Purge valve
28 Column connection capillary
6.1831.010 PEEK capillary,
length L = 30 cm
40 Aspirating capillary
Connection for 6.1834.010 aspirating
tubing
29 Sample loop 10 µL
6.1825.230 PEEK sample loop
41 Fastening screws
for pump head 42
30 Connection capillary to syringe
6.1803.020 PTFE tubing,
length L = 30 cm
42 Pump head (6.2824.100)
31 Rotary nipple for aspirating tube
for fixing the aspirating tube
43 Connection capillary
Connection pump head – purge
valve, fixed mounting
32 Injection valve 44 Connection capillary
in pump head, fixed mounting
33 PEEK coupling (6.2744.040) 45 Inlet capillary for detector block
PEEK capillary, fixed mounting
34 Leak detector 46 Detector block (1.732.0110)
35 Connection capillary
6.1831.010 PEEK capillary,
length L = 13 cm
