24 | i5000™ MetroMark™ Manual
Doc. No.: R12015 Metrotech Copyright © 2008
6
Menu System
6.1 i5000 MetroMark™ Menu System
The receiver’s menu system includes six (6) selectable menus for conguring the i5000™. Press the <Menu>
softkey from the operational interface to access the main menu.
6.2 Main Menu
To access the main menu, press the <Menu> softkey from the operational interface.
The desired menu is selected using the 4-way navigation button. Press the button up/down/left/right to select
the desired menu option. The selected menu is highlighted on the interface as well as labeled at the top of the
display.
Figure 6-1 Main Menu Selection
6.2.1 Frequency Menu
The Frequency menu activates or deactivates any of the available receiver frequencies. Depending on the con-
guration of your i5000 MetroMark receiver, the following frequencies may be available. See the table below for
the available frequencies.
Region Base Frequency Set (Hz)
North America 491, 982, 8.44k, 9.82k, 35.4k, 82k, 83k, 50, 60, 100, 120,
RF
International 491, 512, 577, 640, 982, 8k, 8.44k, 9.82k, 35.4k, 65.6k,
82k, 83k, 50, 60, 100, 120, RF
Electronic Utility Markers 66.35k, 77.0k, 83.0k, 101.4k, 121.6k, 145.7k, 169.8k
To allow easier navigation, the available frequencies are organized into several groups. To access the frequency
menu, use the 4-way navigation button to highlight ƒ. The chosen menu is also labeled at the top of the menu
screen.
Press the <Select> softkey to open the desired menu screen. Press <Back> to return to the operational interface.
Use the 4-way navigation button to select another menu.
