Operation
thermoMETER CTL
Display Mode [Sample] Adjustment Range
S ON Laser sighting [On] ON/ OFF
142.3C Object temperature (after signal processing)
[142.3 °C]
Fixed
127CH Sensor temperature [127 °C] Fixed
25CB Box temperature [25 °C] Fixed
142CA Current object temperature Fixed
MV5
Signal output channel 1 [0 - 5 V]
0 - 20 = 0 - 20 mA/
4 - 20 = 4 - 20 mA/
MV5 = 0 - 5 V/
MV10 = 0 - 10 V/
TCJ = Thermocouple type J/
TCK = Thermocouple type K
E0.970 Emissivity [0.970] 0.100 ... 1.100
T1.000 Transmission [1,000] 0.100 ... 1.100
A 0.2 Signal output Average [0.2 s] A---- = inactive/0.1 ... 999.9 s
P---- Signal output Peak hold [inactive] P---- = inactive/0.1 ... 999.9 s/P oo oo oo oo =
infinite
V---- Signal output Valley hold [inactive] V---- = inactive/0.1 ... 999.9 s /V ∞ = infinite
u 0.0 Lower limit temperature range [0 °C] depending on model/ inactive at TCJ- and TCK-
output
n 500.0 Upper limit temperature range [500 °C] depending on model/ inactive at TCJ- and TCK-
output
[ 0.00 Lower limit signal output [0 V] According to the range of the selected output
signal
