Page 84
Operation
thermoMETER CTL
Display Mode [Sample] Adjustment Range
] 5.00 Upper limit signal output [0 V] According to the range of the selected output
signal
U °C Temperature unit [°C] °C/°F
/ 30.0 Lower alarm limit [30 °C] depending on model
// 100.0 Upper alarm limit [100 °C] depending on model
XHEAD Ambient temperature compensation
[Sensor temperature]
XHEAD = sensor temperature/ -40.0 ... 900.0 °C
(for CTL) as fixed value for compensation/ return-
ing to XHEAD (sensor temperature) by pressing
and together
M 01 Multidrop address [1] (only with RS485
interface)
(only with RS422 Interface)
01 ... 32
B 9.6 Baud rate in kBaud [9.6] 9.6/19.2/38.4/57.6/115.2 kBaud
