9
2.4.2
Rear
panel
128 Model
:
(1)
Serial port (RS-232 Port)
(2)
Remote control port (Remote Port)
(3)
Printer Port
(4)
High voltage correction output connector
(5)
AC power input (230/1
15 V
AC)
(6)
1
15/230V
switch
(7)
Fuse Holder 250V/T1.25A
.
(8)
Audio output socket
Note:
1.
Please confirm whether
the
AC inpu
t voltage setting is the same as the
voltage used.
2.
The input power m
ust be grounded when using the machine.
9
11
