APPENDIX B Test Range and Functions
Item
Symbol
Test range
Error range
Minimum test
voltage
<256
512
Resistance
R
0.10 - 1.99
±20%
R
2.00 - 4.99
±10%
R
5.00 - 49.99
±5%
R
50.00 - 99.99K
±2%
R
100.0K - 199.9K
±5%
R
200.0K - 499.9K
±5% / 10%
R
500.0K - 999.9K
±5% / 10%
R
1.00M -1.99M
±10%
Capacitance
C
1pF-19.99pF
±20%
C
20.00pF-39.99pF
±10%
C
40.00Pf - 3.0uF
±5%
Conduction
COND
0.1 - 50.0
±1%
Insulation resistance
IS
1M - 1.99M
±10%
50V
IS
2.00 M - 4.99 M
±10%
50V
IS
5.00 M - 9.99 M
±10%
50V
IS
10.00 M - 19.99 M
±10%
50V
IS
20.00 M - 49.99 M
±10%
50V
IS
50.00 M - 99.99 M
±10%
100V
IS
100.0 M - 199.9 M
±10%
200V
IS
200.0 M - 499.9M
±20%
500V
IS
500 M - 1000.0M
±20%
1000V
Diode
D
0.6 - 6.8V
±25%
>=7.0V
---
Short circuit
determination value
O/S
2K - 100K
±10%
Intermittence test
20 - 2K
±10%
Unilateral test
1pF-999pF
±20%
HIPOT current
leakage
0.02mA-0.0499mA
±50%
0.05mA-0.099mA
±20%
0.1mA-0.199mA
±20%
0.2mA-0.499mA
±20%
0.5mA-4.99mA
±10%
