43
[2] START UP MODE:
AUTO SCAN Starts test after the DUT is inserted.
MANUAL Press the Test button after the DUT is placed to start the test.
CONTINUE Continuous tests are performed after the Test button is pressed.
[3] AUTO SCAN DELAY:
This is only effective when Automatic is selected as the test start method; its function is to wait a few
seconds before starting the test after the DUT is inserted.
[4] REPEAT INTERNAL:
The cable activation mode is the repeat test interval of repeat test.
[5] REPEAT COUNT:
This is only effective when Continuous is selected as the test start method; it allows setting of the
number of times to test.
[6] BREAK IF FAIL:
If errors occur during test, there are three options displayed at all times: {Stop test}, {Do not test high
voltage} and {Finish all tests}.
[7] STEP TEST FAIL:
REPEATTEST: When the cable type is point test and this step test fails, repeat this step test.
BACK FIRST: When the cable type is point test and this step test fails, return to the first step test.
[8] OS TEST REPEAT:
YES: Continue test when short-circuit test fails; determines test result as FAIL when DUT is
removed.
NO: Determines test result as FAIL when short-circuit test fails.
[9] MANUAL REST DELAY:
When the test button is pressed, delay in the length of time set and then start test.
