Midas DL431 - FOH and MON

14 Chapter 2: XL8 Live Performance System Overview
DL431 Mic Splitter
Operator Manual
FOH and MON
The XL8 Live Performance System can be used as a front of house (FOH) or a stage
monitor (MON) system. Also, by sharing the four mic splitters, these two types of
system can be used in tandem, as shown in Figure 2 on page 14.
Figure 4 on page 21 shows in more detail the interconnections between each unit in a
typical XL8 Live Performance System FOH and MON set up. In particular, it shows the
how the FOH and MON sections are connected up; notice that the mic splitters are
shared between them.
Figure 2: Typical XL8 Live Performance System FOH and MON set-up
Multiple MidasNET links
XL8 Control Centre
Routers
FOH
FOH (on stage)
Stage
Monitor
Mic splitters (shared)
Local I/O units
XL8 Control Centre
DSP units
I/O units (outs)
Key
24-channel bi-directional
MidasNET
Main
Duplicate
Main
Duplicate
192-channel bi-directional
MidasNET trunk link
Main
Duplicate
Routers
DSP units
I/O units (outs)
