Environmental Factors
Use
The VetPro DC Animal Health Dental X-ray System is intended for indoor use for
normal dental applications at temperatures in the range +10 °C to +35 °C (+50 °F
to +95 °F) and at a maximum altitude of 12,000 ft (3657 m). Do not allow humidity
to cause condensation to form on the unit. See the Specifications section on
page
Error! Bookmark not defined.
for complete temperature, pressure, and
altitude parameters for using, transporting, and storing the VetPro DC system.
Support Requirements
The VetPro DC Animal Health Dental X-ray System is designed to mount on a
single wood 2x4-inch drywall stud or equivalent wall support. It can also be
mounted on concrete or other similar wall construction.
Mounting to a plywood
or particle board wall is not acceptable
. Verifying the wall support capability
and the selection of the proper mounting hardware is the responsibility of the
installer.
Note that a two-stud wall plate assembly (30-A2042) is included to mount on two
wooden studs. A metal stud mounting kit (30-A2043) is available.
The wall support and mounting hardware must withstand a 45.4 kg (100 lb.) shear
load and a 227 kg (500 lb.)
withdrawal force at each of the mounting bolts. The
wall fabrication and attachments to the building structure must be capable of
withstanding a load moment of 127 kg-m (920 lb-ft).
Electrical Requirements
Mains Power
Supply
The VetPro DC Animal Health Dental X-ray System requires a 3-wire single phase
AC power mains that contain line conductor, neutral conductor, and protective
earth conductor. It is recommended that the unit be installed with a dedicated
electrical line connected to a breaker with a minimum 15 amp rating. The wiring
must provide for a permanently grounded power line configuration.
Line Cord
Use
The installer must determine the suitability of installing the VetPro DC with a line
cord. If a line cord is used, the installer must ensure that the unit is properly
grounded and has the required line rating.
Line Voltage
AC 100 V to 250 V, 50 Hz or 60 Hz (See complete specifications on page 117)
Fuse Rating
5 A, 250 V, UL Recognized (See complete specifications on page 117)
Max Line
Resistance
For normal function of the VetPro DC Animal Health Dental X-ray System the
resistance of the power line should not exceed 0.4 Ω at nominal line voltage.
Interlock
It is the owner’s responsibility to provide any visual interlock
indicators required by local ordinances.
