VetPro DC Installation/Service Manual, 00-02-1606, Revision R01
97
Maintenance
VetPro DC Tubehead Removal Instructions
Overview
Tubeheads are shipped with the yoke cable assembly already premounted to
the tubehead. This guide provides instructions for the installation technician on
how to remove the original head, install the replacement tubehead and, how to
calibrate the replacement tubehead.
Do not remove the tubehead until the articulating arm
assembly has been secured with the provided cable tie and
foam insert. The spring tension is adjusted to account for
the weight of the tubehead. The articulating arm will spring
open and can cause serious injury if it is not secured.
Models
Affected
All VetPro DCs
Required
tools
Spanner wrench (30-T0055)
Needle nose pliers
Metric hex keyes
#2 Phillips head screw driver
#1 Small Phillips head screw driver
Fluorescent screen (22-11467)
Instructions
Figure 73
1. The replacement head as received will have the yoke cable assembly
pre attached.
NOTE:
Do not remove the yoke cable from the tubehead.
