VetPro DC Installation/Service Manual, 00-02-1606, Revision R01
75
Diagnostic Mode
The VetPro DC Animal Health Dental X-ray System has a diagnostic mode in
which you can display a summary of maintenance data or display feedback
values after each exposure.
Maintenance
Summary
1. From the Main System Configuration menu, Figure 54, select
CONFIGURE UNIT. You will see the Configuration menu shown in Figure
57.
2. Select SET CONFIG. You will see the Set Configuration menu, shown in
Figure 58.
3. To display a summary of maintenance data, highlight select SHOW
MAINT. The following maintenance data are displayed:
• Total KJ (kilojoules—total system heat on the X-ray tube)
• Exposure Count
• Reboots (power up cycles)
• OT Counts (over-threshold counts)
4. Press any button on the Operator Panel to return to the Configuration
Showing
Feedback Values
After an
Exposure
If you take an X-ray while in diagnostic mode, the display shows feedback
values for that exposure. Until you exit diagnostic mode, the display will
continue to show feedback values after each exposure.
1. From the Main System Configuration menu, Figure 54, select
CONFIGURE UNIT. You will see the Configuration menu shown in
Figure
57.
2. Select SET CONFIG. You will see the Set Configuration menu, shown in
Figure 58.
3. From the Set Configuration menu, use the up and down arrows to
highlight DIAG MODE ON. Press the right arrow button to turn on
diagnostic mode.
4. Exit System Configuration mode by highlighting and selecting EXIT in the
Configuration and Main menus.
5. Make an exposure. The display will show the following feedback values:
• kV
• mA
• Filament current
6. Press any button on the Operator Panel to clear the feedback values from
the display.
7. To exit diagnostic mode, press the Tooth Selection and Patient Size
Selection buttons simultaneously for 5 seconds to display the Main
System Configuration menu. From the Main menu, highlight and select
CONFIGURE UNIT. Then highlight and select SET CONFIG. On the Set
Configuration menu, highlight and select DIAG MODE OFF.
Note: Feedback values are approximate.
