VetPro DC Installation/Service Manual, 00-02-1606, Revision R01
63
Installing the Remote Exposure Station (30-A2044)
The Remote Exposure Station is an option for the VetPro DC that allows the
operator to make the exposure from a fixed location remote from the main unit.
As shown in
Figure 45, a single switch can be used, or two switches can be
used in series or in parallel. Two switches in series will require both switches to
be pressed simultaneously to make an exposure. If two switches are used in
parallel, only one needs to be pressed to make an exposure.
The following tools are required to install the switch:
• Phillips screwdriver
• Flat-blade screwdriver
• Telephone cable stripper (for dual switch configuration only)
• Wire stripper (for dual switch configuration only)
